Product Description
The APEX 10 is a high-performance, Level 2 EV charging station that delivers up to 11,500 Watts (11.5 kW) of clean charging power. With a 48A adjustable output, sleek wall-mounted design, and built-in 4.3" LCD screen, this unit is both aesthetically refined and technologically advanced.
Designed for long-term deployment in residential buildings, hospitality venues, and multi-family dwellings, the APEX 10 features full OCPP 1.6 JSON compatibility, LAN/Wi-Fi connectivity, and optional RFID or credit card authentication.
This package includes a 2-Year Cloud Networking Subscription and a One-Time Commissioning Fee, ensuring the charger arrives fully configured and ready for public use—complete with an IoT SIM card, firmware updates, OCPP URL setup, and application of QR codes & instructional stickers.
Two premium pedestal options are available to complement your installation: the DYNO Pedestal with integrated cable management for a clean, organized setup, or the minimalist MP Pedestal for a sleek, modern profile.
What’s Included
-
APEX 10 Wall-Mounted EV Charger (48A, 11.5 kW Max Output)
-
4.3" LCD Display Screen
-
16.4 ft SAE J1772 Charging Cable
-
Wi-Fi, LAN, & IoT SIM Card Connectivity
-
2-Year Cloud Networking Subscription (For Public Use)
-
One-Time Commissioning Service, which includes:
-
Initial Firmware Update
-
OCPP URL Configuration
-
Full System Testing
-
QR Code & Instruction Sticker Application
-
Charger Specifications
| Specification | Details |
|---|---|
| Power Output | 16A–48A (Adjustable) – Up to 11.5 kW |
| Input Voltage | 200–240V AC |
| Mounting Type | Wall-Mounted |
| Display | 4.3" LCD Display |
| Connector Type | SAE J1772 (16.4 ft Cable) |
| Connectivity | LAN, Wi-Fi, IoT SIM |
| OCPP Compatibility | OCPP 1.6 JSON (2.0 Compatible) |
| Authentication | App, WebApp, ISO 15118 (RFID, Credit Card Optional) |
| Operating Temperature | -22°F to 122°F (-30°C to 50°C) |
🚀 Key Features
⚡ High-Powered Charging – Up to 11.5 kW, 48A adjustable output
📱 User-Friendly Display – Built-in 4.3" LCD screen
🌐 Connected & Smart – OCPP 1.6, LAN/Wi-Fi + IoT SIM for public deployment
🔐 Flexible Authentication – ISO 15118, RFID, Credit Card Optional
🛠 Public Use Ready – Includes cloud access & commissioning services
🏘 Ideal for Shared Spaces – Perfect for residents, hotels, and multifamily units
Certifications
ETL Certified
OCPP Compliant
Ideal For
-
Residential Buildings
-
Hospitality Properties
-
Multi-Family Complexes
-
Public Parking Garages
-
Workplace Charging Programs
