Product Description
The EVBolt Dual-Port Level 2 Commercial EV Charger is the most powerful dual-port AC charger available, engineered for commercial charging stations with limited space. With a 21.5-inch TFT LCD screen offering 1080P resolution, this system can also double as an interactive advertising platform, creating new revenue streams. Ideal for commercial settings, it provides robust functionality combined with sleek design, offering up to 11.5 kW at 48A per port for fast and reliable charging.
The EVBolt Dual-Port Charger includes two built-in 4.3" touch-screen interactive displays, a USB/SD card port for offline advertising, and seamless online advertisement capabilities through EVBOLT Cloud. The package also includes a 2-Year Cloud Networking Subscription with an IoT SIM card for internet connectivity and a One-Time Commissioning Service to ensure a smooth installation process.
What’s Included:
EVBolt Dual-Port Level 2 Charging Station (11.5 kW, 48A per port)
21.5" TFT LCD Screen (1080P) with advertising functionality
Two 4.3" Touch-Screen Interactive Displays
Dual 16.4 ft SAE J1772 Charging Cables
LAN + Wi-Fi + 4G Connectivity (IoT SIM for cloud access)
2-Year Cloud Networking Subscription
Commissioning Service, which includes:
-
-
Firmware Update
-
OCPP URL Setup
-
Full System Testing
-
QR Code & Instruction Sticker Installation
-
Charger Specifications
| Specification | Details |
|---|---|
| Power Output | 48A per port (up to 11.5 kW) |
| Input Voltage | 200–250V AC |
| Mounting Type | Wall-Mounted |
| Display | 21.5" TFT LCD + Dual 4.3" Touch Screens |
| Connector Type | Dual SAE J1772 (16.4 ft Cables) |
| Connectivity | LAN + Wi-Fi + 4G (IoT SIM for Internet) |
| OCPP Protocol | OCPP 1.6 JSON (2.0 Compatible) |
| Authentication | App, WebApp, ISO 15118 (Optional: RFID, Credit Card) |
| Operating Temperature | -22°F to 158°F (-30°C to 70°C) |
Key Features
11.5 kW High-Speed Charging – Up to 48A per port for ultra-fast charging
21.5" Interactive LCD Screen – 1080P resolution for advertising & user information
Commercial-Grade – Ideal for businesses, public spaces, and charging stations
Smart Connectivity – LAN, Wi-Fi, and 4G for cloud-ready access with IoT SIM
Dual Port Charging – Convenient charging for two vehicles simultaneously
Advertisement Revenue – Generate revenue through online & offline advertising
Flexible Access Options – App, Web, ISO 15118, optional RFID/Credit Card
Certifications
ETL Certified
Energy Star Certified
OCPP 1.6 JSON Compliant
Ideal For:
Commercial Charging Stations
Public Parking Facilities
Multi-Family Residential Properties
Retail Locations & Shopping Malls
Workplace & Employee Charging
EV Charging Projects
Product Data sheet Specifications:
