📝 Product Description
The AC Fast EV Charger delivers cutting-edge performance in a compact wall-mounted design. With a maximum output of 11.5 kW (48A), this Level 2 charger is ideal for commercial, fleet, and public charging applications.
Built for durability and low maintenance, it features a 4.3" LCD touchscreen for a modern, user-friendly interface and supports App, WebApp, and ISO 15118 authentication. The charger includes a 16.4-ft SAE J1772 cable, OCPP 1.6 JSON (2.0 compatible) connectivity, and supports Wi-Fi and 4G via an included IoT SIM card.
The package price includes a 2-Year Cloud Networking Fee and a one-time commissioning service, covering initial firmware updates, OCPP setup, testing, and installation-ready QR and instruction stickers—making it truly turnkey for public use.
Two premium pedestal options are available to complement your installation: the DYNO Pedestal with integrated cable management for a clean, organized setup, or the minimalist MP Pedestal for a sleek, modern profile.
⚙️ What’s Included
-
AC Fast Charger Unit (Wall-Mounted, 48A, 11.5 kW Output)
-
4.3" LCD Touchscreen Interface
-
16.4-ft SAE J1772 Charging Cable
-
IoT SIM Card for Internet Connectivity
-
2-Year Cloud Networking Subscription (For Public Use)
-
One-Time Commissioning Service, which includes:
-
Initial Firmware Update
-
OCPP URL Setup
-
System Testing
-
QR Code & Instruction Stickers
-
🔋 Charger Specifications
| Specification | Details |
|---|---|
| Power Output | Switchable 16A to 48A (Up to 11.5 kW) |
| Input Voltage | 200–240V AC |
| Mounting Type | Wall-Mounted |
| Display | 4.3" LCD Touchscreen |
| Connector Type | SAE J1772 (16.4-ft Cable) |
| Connectivity | Wi-Fi, 4G (IoT SIM), OCPP 1.6 JSON |
| OCPP Compatibility | 1.6 JSON (2.0 Compatible) |
| Authentication | App, WebApp, ISO 15118 (RFID, Credit Card Optional) |
|
Operating Temperature |
-22°F to 131°F |
🚀 Key Features
⚡ High-Powered Level 2 Charging – 48A output and up to 11.5 kW
📱 Smart User Interface – Intuitive 4.3" LCD touchscreen
🌐 Connected & Compliant – OCPP 1.6 JSON + Wi-Fi & 4G via SIM
🔒 Flexible Authentication – App, ISO 15118, RFID & Credit Card ready
🛠 Low Maintenance Design – Built to last with minimal upkeep
📦 Public Deployment Ready – Includes cloud access and commissioning
🛡️ Certifications
✅ ETL Certified
✅ Energy Star Rated
✅ Ideal For
-
Fleet Charging Operators
-
Public Parking & Retail Locations
-
Workplace EV Charging
-
Commercial Properties
-
Municipal & Utility Programs
