Product Description
The EVBolt PRESTIGE 11 is a cutting-edge, high-powered Level 2 AC fast charger, delivering up to 11.5 kW with an adjustable output range of 6A–48A. Featuring an elegant and compact design, this charger is built for high-performance charging while ensuring an easy user experience. Whether for residential properties, multi-family units, hospitality settings, or public spaces, this charger provides a seamless charging solution.
With its sleek 5" LCD display, LAN + Wi-Fi connectivity, and OCPP 1.6 JSON support (compatible with 2.0), the PRESTIGE 11 enables real-time monitoring, access control, and a reliable connection for public use. The package includes a 2-Year Cloud Networking Subscription and an IoT SIM card, along with a commissioning service that covers firmware updates, system testing, and QR code installation for easy use.
Two premium pedestal options are available to complement your installation: the DYNO Pedestal with integrated cable management for a clean, organized setup, or the minimalist MP Pedestal for a sleek, modern profile.
What’s Included
PRESTIGE 11 Wall-Mounted Charger Unit (48A / 11.5 kW Output)
5" LCD Display showing real-time charging stats
16.4 ft SAE J1772 Charging Cable for easy vehicle connection
LAN + Wi-Fi Connectivity (IoT SIM card included for cloud access)
2-Year Cloud Networking Subscription for public access and monitoring
Commissioning Service including:
-
-
Initial Firmware Update
-
OCPP URL Setup
-
Full System Testing
-
QR Code & Instruction Sticker Installation
-
Charger Specifications
| Specification | Details |
|---|---|
| Power Output | 6A–48A Adjustable (Up to 11.5 kW) |
| Input Voltage | 200–240V AC |
| Mounting Type | Wall-Mounted |
| Display | 5" LCD Screen |
| Connector Type | SAE J1772 (16.4 ft Charging Cable) |
| Connectivity | LAN + Wi-Fi (IoT SIM for Internet Access) |
| OCPP Protocol | OCPP 1.6 JSON (2.0 Compatible) |
| Authentication | App, WebApp, ISO 15118 (Optional: RFID, Credit Card) |
| Operating Temperature | -22°F to 122°F (-30°C to 50°C) |
Key Features
11.5 kW High-Speed Charging – Adjustable output up to 48A for faster charging speeds
5" LCD Display – Clear and real-time charging statistics for easy tracking
Smart Connectivity – LAN + Wi-Fi, cloud-ready with IoT SIM for internet access and monitoring
Flexible Access Control – App, Web, ISO 15118 with optional RFID or Credit Card payment integration
Public-Use Ready – Pre-commissioned, cloud-enabled, and install-ready
Ideal for Residential & Commercial Sites – A versatile solution for all property types, including multi-family and commercial projects
Certifications
UL Certified for safety and quality
Energy Star Certified for energy efficiency
CTEP Compliant to meet California's metering and safety standards
OCPP 1.6 JSON Compliant for compatibility with most back-office systems
Ideal For
Multi-Family Residential Properties
Hotels & Resorts
Workplace & Employee Charging
Public Parking Facilities
Commercial EV Projects
Product Data Sheet Specifications:
EVBOLT APP Operating Instructions
